■Product Features |
■Passed the national authority explosion-proof certification, produced in full accordance with national explosion-proof standards, the highest explosion-proof level, can work safely in flammable and explosive places.
■Use high-intensity gas discharge lamp as the light source, with high light efficiency, high color rendering, soft light, uniform illumination, and an average service life of more than 20,000 hours.
■ High-tech surface spraying treatment is used to prevent rain and corrosion, and never rust. The transparent parts use the latest photocatalyst nano-materials, which can automatically decompose stains and do not stick to oil to ensure the lighting brightness of the lamps.
■ The shell is made of special high-hardness alloy material, with multiple shock-absorbing structures, which has strong shock and shock resistance, and can be used for a long time in various harsh environments outdoors.
■ Product Parameters |
Item | Symbol | Description | Unit |
Picture |
| ||
Rated Voltage | VOLT | 220 | V |
Power | P | 250/400 | W |
Lighting Source | / | MH/HPS | |
Protection Level | IP | IP65 | IP |
Lighting Angle | θ | 90/120 | ° |
Anti-corrosion Grade | / | WF2 | |
Explosion Proof Grade | / | Ex d IIC T4/T6 | |
Light Efficiency | η | 90 | Lm/W |
Frequency | f | 50/60 | Hz |
Power Factor | PF | ＞0.90 | PF |
Operating Temperature | TOPR | -30~50 | ℃ |
Storage Temperature | TOPR | -30~50 | ℃ |
| Color Rendering Index | CRI | ≥65 | RA |
LED'S Operating Life | LIFE | 50000 | Hours |
Start-up Time | T | ≤20 | S |
Executive Standard | / | GB3836.1、GB3836.2 | |
Weight | / | 11.0 | KG |
Size | / | 540x364x192 | MM |
